Pari 2: Important Installation
n*'Before your appliance is
connected to the gas supply,
check the ensure that the gas
category and pressure
specifications shown in the data
plate corresponds with your gas
supply. If necessary call
authorized service for
adjusting to gas category.
^This appliance shall be
installed in accordance with the
regulations in force and only
used in a well ventilated space.
Read the instructions before
installing or using this appliances.
In the interest of safety this
appliances must be installed
and/or serviced by a competent
person as stated in the gas safety
regulations current editions.
^ Please refer to the data plate
for details about gas supply and
pressures.
^ The appliance must not be
installed in a room without a
window or other controllable
opening. If is installed in a room
without a door which opens
directly to fohe outside, a
permanent opening is required.
The air circulation should be 2
m3/h per kW of burners.
Conitecflon of tho gas hoso
fe tho oven
Convenient position is selected by
interchanging the hose nozzle and
plug according to the location of the
main gas inlet valve. If you make a
connection with a flexible metal hose
, locate a seal between the main gas
pipe. The inner diameter of the flexible
hose, which the butane hose nozzle is
connected, should be 6mm for the
house-type gas tubes.
The inner diameter of the flexible hose,
which the natural hose nozzle is
connected, should be 15mm. The hose
should tightly be fitted to the hose
nozzle by squeezing with a clamp. The
plastic hose end is soaked in hot water
for one minute to soften and inserted
fully into the hose nozzle. The clamp
is fastened securely by a screw driver.
The other end of the hose is connected
to the gas valve with the same
operation.
The hose should be replaced before
its last expiry date.
Caution!
Make the oven connection to the
gas inlet valve, the hose length
must be short and be sure that
there is no leakage. The hose
used should not be longer than
125 cm for safety.
and preparation of your oven
Connection of the gas hose
to the even
Convenient position is selected by
interchanging the hose nozzle and
plug according to the location of
the main gas inlet valve. The plastic
hose end is soaked in hot water
for one minute to soften and
inserted fully info the hose nozzle.
The clamp is fastened securely by
a screw driver. The other end of
the hose is connected to the gas
valve with the same operation.
Oas ieakagu controi
During control, be sure that the
control knobs are closed and the
gas inlet valve is open. Apply soap
bubbles to the connections for
leakage control. In case leakage
exists, buble will appear. In such
case, check the gas connection
immediately. Do not control gas
leaks by using fire.
Caution!
Never use lighter or
match fíame, for
controlling the gas
lackage.
hose
nozzle
LPG
^ n.- rr, 1 O-ring
(seal)
Clamp
Tube
Hose nozzle and
elbow types for
Natural gas and
Butane/propane
