ENGLISH
Attaching the Charged Battery
Insert the Battery with its top (the end
with the Charge Confirmation Marker)
into the top Battery Holder.
Press the bottom of the Battery toward
the Movie Camera until it locks with a
click.
•The remaining battery power can be confirmed
with the Remaining Battery Power Indication
1
2
• iwit&iiaai, [Csjli§^#rAiJs,
3 i?3j®[powER]^Bii,
/ j S o
◄BATTERY EJECTjffi, (iJBt
iidiWitilo
•After attaching the Battery, the Remaining Battery
Power Indication briefly indicates a fully charged
Battery regardless of the actual charging
condition. After a few seconds, it indicates the
actual remaining battery power.
•When the Battery is exhausted, the [ [3 1
Indication flashes and the Movie Camera
automatically turns off.
3
4
Removing the Battery
Turn in the [POWER] Switch to turn the
Movie Camera off.
Hold the Battery firmly to prevent it
from dropping and pull it off while
sliding the [◄ BATTERY EJECT] Lever
in the direction of the arrow.
24
