awiiiio
•iig^su,
^^mmmo
mmm mmmimmm/mmkxm^i)
[ V I D E O O U T ] ----------------- > V I D E O I N ( f ^ i t )
[ A U D I O O U T l — ^ A U D I O I N ( ^ $ i )
3 ii[VCR/CAMERA]M,iSii[VCRj)|^slo
• [VCRlis^^aO^i^-
•
AftiLsi, pjj^'jz-^$
* R F H ® S ( V W - R F 7 E , i iP , S | i # f t ) „
Watching Playback on a TV Set
By connecting the Movie Camera to a TV, you can
watch playback of the recorded scenes on the TV
screen.
• Before connecting, turn off both the Movie Camera
and the TV for safety’s sake.
1
Use the AV Cable (supplied) to connect
the Movie Camera with the TV.
Movie Camera
TV (AV Input Sockets)
[VIDEO OUT] --------------> VIDEO IN
[AUDIO OUT] ------------- > AUDIO IN
2
Seiect the channei on the TV which
corresponds to the video/audio input
sockets used for connecting.
(Refer to the operating instructions of your TV).
3
Press the [VCR/CAMERA] Button to
select the VCR Mode.
•The [VCR] Lamp Q lights.
4
start playback on the Movie Camera.
(-►66)
• If your TV is not equipped with AV Input Sockets, the
RF Adaptor (VW-RF7E; optional) is necessary.
Consult your dealer.
70
