ENGLISH
Adjusting the Finder
Before adjusting the Finder, make sure that the LCD
Monitor is completely closed.
1 Connect the AC Adaptor or attach a
charged Battery.
2 Turn out the [POWER] Switch to turn the
Movie Camera on.
• The [CAMERA] Lamp O lights.
3 If necessary, extend the Finder
backward and adjust its angle upward.
•The Finder can be tilted upward up to 90°.
4 Look in the Finder and turn the
Eyepiece Corrector Ring 0 clockwise
or counterclockwise.
• Stop turning the Eyepiece Corrector Ring at the
point where the indications in the Finder are
sharpest.
Never aim the Movie Camera with its Finder or Lens
directly at the sun; this could damage internal parts of
the unit.
Adjusting the Grip Beit
Adjust the length of the Grip Belt so that you can easily
press the Recording Start/Stop Button © with your
thumb and push the [W • T] Zoom Lever O with your
index or middle finger.
Handiing the Lens Cap
Remove the Lens Cap from the Lens Hood and hook it
onto the Grip Belt ©.
44
