Страница 34: Inserting the cassette
Внимание! Текст в этом документе был распознан автоматически. Для просмотра оригинальной страницы Вы можете воспользоваться режимом "Оригинал".
(-►20,28)
3 i^:&}m[AOPEN]m,minmm^^,
•
a#, wMBm
iM^rnmmmii«¿Fiiiiiitio
4 15i?5S№/T^, ;§№ [AEJECT] (#pdJ)
m&o
5
p ©f^^,
n
nmmj&o
6
IS±5i®^M, ^iti$[LOCK]MOo
flsiiiiwis, ;f»)[AEJECT]ffi0,
e[LocK](iS5i:)iaO,
2
3
Inserting the Cassette
1
Connect the AC Adaptor or attach a
charged Battery. {-¥ 20,28)
Turn the cog wheel Q to tighten the
tape.
Slide the [AOPEN] Lever to the left and
simultaneously open the LCD Monitor
in the direction of the arrow
approximately 90°.
• Be sure to keep the LCD Monitor in its vertical
position, so that the Cassette Compartment
Cover, when it opens, does not hit the LCD
Monitor.
Slide the EJECT] Lever Q in the
direction of the arrow.
Insert the cassette with the cassette
window 0 facing outward and push it
all the way in.
6 Close the Cassette Compartment by
pressing the [LOCK] Button Q-
■ Ejecting the Cassette
Slide the EJECT] Lever 0 in the direction of the
arrow and pull out the cassette.
Close the Cassette Compartment by pressing the
[LOCK] Button O.
4
5
38
