73

Культиватор X-Press

Инструкции по эксплуатации

AS2725

SCrAPer rAIl ASSembly - X-PreSS 2.5m

ITem

PArT no.

DeSCrIPTIOn

QTy

COmmenTS

1

P00407

BOLT M20x80 GR. 8.8

4

2

P01834

BEARING SCJ 50

2

3

P02007

NUT LOCK M12

8

4

P02009

NUT LOCK M20

4

5

P02601

WASHER FLAT M12

8

6

P02603

WASHER FLAT M20

8

7

P03714

BUSH SPRUNG - Ø26xØ20x20

4

8

P10944

SCREW M12x50 GR10.9 CSK

16

9

P12758

STUB AXLE END WASHER Ø50

2

10

P12950

BOLT M12x35 SOCKET CAP

4

11

P12959

DD550 RING - Ø358

32

12

P13026

RING - RETAINING

2

13

P13072

SPACER RUBBER 57mm

15

14

P13073

SPACER RUBBER 26mm

2

15

P14276

ROLL TUBE 2.5m X-PRESS

1

16

P14849

BUSH Ø18xØ13x15

8

17

P15170

DD LIGHT ROLL FRAME 2.5m

1

18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50

7. Комплектующие и узлы
