45 Культиватор X-Press
Инструкции по эксплуатации
AS2711 ChASSIS ASSembly - X-PreSS 3.0m
ITem PArT no. DeSCrIPTIOn QTy COmmenTS
1 AS2708 PROACTIVE UNIT - RH 11
2 AS2709 PROACTIVE UNIT LH 11
3 P00874 BOLT M20x70 GR. 8.8 4
4 P01704 BOLT M16x50 GR8.8 44
5 P01901 BOLT M16x80 GR. 8.8 44
6 P02008 NUT LOCK M16 88
7 P02009 NUT LOCK M20 4
8 P02484 LYNCH PIN CAT 2 3
9 P02602 WASHER FLAT M16 88
10 P05122 SERIAL PLATE 1
11 P07981 NUT LOCK M6 4
12 P11462 DISC BLADE Ø515x6 22
13 P12349 BOLT M6x30 4
14 P12620 TOP PLATE 22
15 P12621 SPACER Ø36xØ16.5x31mm 44
16 P12622 TRACK ARM 22
17 P12783 LYNCH PIN CAT 0 22
18 P12810 NUT CASTLE M24 22
19 P12815 BOLT M24x185 STRUCTURAL GR 8.8 22
20 P12886 Ø24xØ16x13mm SPACER BUSH 22
21 P12897 TRACK ROD RH FRONT 5.5m X-PRESS SL 1
22 P13092 RIVET Ø3x10x Ø6 HEAD 4
23 P13112 LOWER LINK PIN 2
24 P14015 TRACKROD REAR 1
25 P14050 POINTER 2
26 P14055 SPACER BUSH - 10mm 4
27 P14481 GANG ANGLING JACK 2
28 P14980 CHASSIS - X-PRESS 3m 1
29 P14982 UPPER LINK PIN 1
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
