49 Культиватор X-Press
Инструкции по эксплуатации
AS2721 ChASSIS ASSembly - X-PreSS 4.0m F/W
ITem PArT no. DeSCrIPTIOn QTy COmmenTS
1 P00001 BOLT M10x40 GR.8.8 2
2 P00002 BOLT U M12 GR8.8 70x54 2
3 P00014 BOLT M24x80 GR. 8.8 6
4 P00036 BOLT M30x180 GR. 8.8 1
5 P00071 NIPPLE - GREASE 4
6 P00941 BOLT M30x90 GR. 8.8 2
7 P02007 NUT LOCK M12 5
8 P02010 NUT LOCK M24 6
9 P02011 NUT LOCK M30 3
10 P02483 LYNCH PIN CAT 1 2
11 P02484 LYNCH PIN CAT 2 3
12 P02600 WASHER FLAT M10 4
13 P02601 WASHER FLAT M12 6
14 P02604 WASHER FLAT M24 Ø50 12
15 P02608 WASHER FLAT M30 3
16 P03093 BOLT M12x75 GR. 8.8 1
17 P05122 SERIAL PLATE 1
18 P05400 WASHER FLAT M6 2
19 P05401 WASHER SPRING M6 4
20 P05534 NUT LOCK M10 2
21 P05820 JUNCTION BOX 1
22 P07544 PLASTIC END CAP 50x50 1
23 P08892 BOLT M6x50 GR. 8.8 2
24 P09092 HOSE STOWAGE PLATE 1
25 P11499 BOLT M6x55 GR. 8.8 2
26 P13092 RIVET Ø3x10x Ø6 HEAD 4
27 P13126 HEADSTOCK BRACE 2
28 P14033 RIVET Ø5x25 2
29 P14072 PIN Ø30x93 2
30 P14075 BUSH Ø52xØ40.6x45 8
31 P14971 LIGHT MOUNT 1
32 P14974 CHASSIS 1
33 P14995 HEADSTOCK PLATE 1
34 P14996 CAT 3 LOWER LINK PIN TO SUIT ST BAR 2
35 P15000 CAT 2/3 UPPER LINK PIN TO SUIT ST BAR 1
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
7. Комплектующие и узлы
