63 Культиватор X-Press
Инструкции по эксплуатации
AS2725 DDlIGhT rOll ASSembly - X-PreSS 2.5m
ITem PArT no. DeSCrIPTIOn QTy COmmenTS
1 P00407 BOLT M20x80 GR. 8.8 4
2 P01834 BEARING SCJ 50 2
3 P02007 NUT LOCK M12 8
4 P02009 NUT LOCK M20 4
5 P02601 WASHER FLAT M12 8
6 P02603 WASHER FLAT M20 8
7 P03714 BUSH SPRUNG - Ø26xØ20x20 4
8 P10944 SCREW M12x50 GR10.9 CSK 16
9 P12758 STUB AXLE END WASHER Ø50 2
10 P12950 BOLT M12x35 SOCKET CAP 4
11 P12959 DD550 RING - Ø358 32
12 P13026 RING - RETAINING 2
13 P13072 SPACER RUBBER 57mm 15
14 P13073 SPACER RUBBER 26mm 2
15 P14276 ROLL TUBE 2.5m X-PRESS 1
16 P14849 BUSH Ø18xØ13x15 8
17 P15170 DD LIGHT ROLL FRAME 2.5m 1
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
7. Комплектующие и узлы
