8
CAUTION
• Switch off the power supply before cleaning.
• Do not touch the aluminium fin, sharp parts may cause injury.
1 INDOOR UNIT
• Wipe the unit gently with a soft, dry cloth.
2 FRONT PANEL
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
POWER
TIMER
AUTO COMFORT
ECONAVI
• Press down both ends of the front panel to close it securely.
3 RECEIVER
4 ALUMINIUM FIN
5 HORIZONTAL AIRFLOW DIRECTION LOUVER
• Manually adjustable.
WARNING
Be carefull not to insert your fingers into
the unit to avoid injuring by cross-flow fan.
6 VERTICAL AIRFLOW DIRECTION LOUVER
• Do not adjust by hand.
7 AUTO OFF/ON BUTTON
• Use when remote control is misplaced or malfunction.
Action
Mode
Press once.
Auto
Press and hold until 1 beep is heard, then release. Cooling
Press and hold until you hear double beep sound,
then release.
Heating
To turn off, press the AUTO OFF/ ON button again.
8 AIR FILTERS
• Clean the filters regularly.
• Wash/rinse the filters gently with water to avoid damage
to the filter surface.
• Dry the filters thoroughly under the shade, away from
fire or direct sunlight.
• Replace any damage filter.
9 HUMAN ACTIVITY SENSOR
• Do not hit or violently press the sensor or poke it with a
sharp object. This can lead to damage and malfunction.
• Do not place large objects near the sensor and keep
away heating units or humidifiers from the sensor’s
detection area. This may lead to sensor malfunction.
2
9
7
1
4
3
8
5
6
INDOOR UNIT
CLEANING INSTRUCTIONS
HINT
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
• To ensure optimal performance of the unit, cleaning
maintenance have to be carried out at regular intervals.
Please consult authorized dealer.
NOTE
• If chemical cloth is used to wipe the unit, instruction for
the cloth should be followed.
