Remote control – Инструкция по эксплуатации Panasonic CS-LE9
Страница 6
6
POWER
TIMER
AUTO COMFORT
ECONAVI
REMOTE CONTROL
Press the remote control’s button
1
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
2
TO SET TEMPERATURE
• Selection range: 16˚C~30˚C.
• Operating the unit within the recommended temperature
could induce energy saving.
HEAT mode: 20˚C ~ 24˚C.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
3
TO SELECT OPERATION MODE
AUTO mode - For your convenience
• During operation mode selection the power indicator
blinks.
• Unit selects the operation mode according to the indoor
intake temperature and remote control temperature.
HEAT mode - To enjoy warm air
• In heat mode, it may take a while for the unit to warm up.
The POWER indicator blinks during preheating.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
4
TO SELECT FAN SPEED (6 OPTIONS)
FAN SPEED
QUIET
• For AUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
QUIET: TO ENJOY QUIET ENVIRONMENT
• This setting provides a quiet environment by reducing the
airflow noise.
5
TO ADJUST VERTICAL AIRFLOW DIRECTION
(5 OPTIONS)
AIR SWING
• Keeps the room ventilated.
• In COOL mode, if AUTO is set, the louver swing up/down
automatically.
• In HEAT mode, if AUTO is set, the louver fix at
predetermined position.
6
TO ACHIEVE TEMPERATURE QUICKLY
• This setting enables the desired set temperature to be
reached quickly.
7
TO MONITOR HUMAN PRESENCE & ACTIVITY
FOR COMFORT
AUTO COMFORT―To maximize comfort
• Press the AUTO COMFORT button, the AUTO COMFORT
indicator on the indoor unit lights up and the ECONAVI
indication is displayed on the remote control display.
8
TO MONITOR HUMAN PRESENCE & ACTIVITY
FOR ENERGY SAVING
ECONAVI―To optimize energy saving
• Press the ECONAVI button, the ECONAVI indicator on
the indoor unit lights up and the ECONAVI indication is
displayed on the remote control display.
NOTES:
Cannot be activated at the same time.
9
PRESS TO RESTORE THE REMOTE CONTROL’S
DEFAULT SETTING
10 NOT USE IN NORMAL OPERATIONS
Maximum distances: 8m
INDICATOR
(Green)
(Orange)
AUTO COMFORT
POWER
ECONAVI
TIMER
(Green)
(Green)
Remote Control display
1
4
5
3
6
10
9
8
7
2
