English - 2
Installing VESA Compliant Mounting Devices (19inch model only)
1. Place the TV face down on a soft cloth or cushion on a table.
2. Adjust the stand, pressing the button on the back of the stand.
3. Align the mounting interface pad (not supplied) with the holes in the stand bottom and secure it with the four screws that come
with the arm-type base, wall mount hanger or other bases (not supplied).
Using the Decoration Covers (19inch model only)
1. When installing the TV on the wall without using the stand, insert decoration covers into the holes as described in the picture
1
.
2. After inserting the decoration covers, fasten them with 4 screws as described in the picture 2.
¦
¦
2
1
Button
Mounting pad
(Sold separately)
1
2
