English - 24
Teletext information is often divided between several pages displayed in sequence, which can be accessed by:
Entering the page number
Selecting a title in a list
Selecting a coloured heading (FASTEXT system)
Teletext level supported by the TV is version 2.5 which is capable of displaying additional graphics or text.
Depending upon the transmission, blank side panels can occur when displaying Teletext.
In these cases, additional graphics or text is not transmitted.
Older TV’s which do not support version 2.5 are not capable of displaying any additional graphics or text, regardless of the
Teletext transmission.
Press the
TV button to exit from the teletext display.
Teletext 16:9, picture is 16:9.
How to Adjust the Stand (19inch model only)
1. Place the front of the TV onto a soft cloth or cushion on a table as in Figure 1.
Align the TV bottom along the table edge.
2. Press on the center of the TV back. Adjust the stand as in Figure 2 while pressing the button on the back of the stand.
3. Place the TV on the table so that the TV sits safely on the table.
How to Adjust the Angle of the TV (19inch model only)
When you adjust the stand, press the button on the back of the stand.
1. Figure 1 shows the adjustment angle (-2°~14°) when you use the LCD on its stand.
Excessive tilting can turn the LCD TV over which may cause damage.
2. Figure 2 shows the adjustment angle (14°~80°) when you convert the LCD from stand-based use to wall-mount.
3. Figure 3 shows the adjustment angle (0°~10°) when you mount the LCD TV to a wall.
You will hear a “Click” sound when changing the angle from 1 to 2 or 3 to 2.
N
–
–
–
N
N
N
N
O
O
¦
–
¦
N
N
1 2
1 Angle adjustment when using
the TV on its stand.
2 Angle adjustment when
converting from Stand to Wall
mount (1→3, 3→1)
3 Angle adjustment when LCD
TV is wall-mounted
