29 (E)

1. Select the pan/tilt head system using the CONTROL/

PREVIEW MONITOR OUT SEL button.

2. Press the button in which the tracing memory data to be

changed has been entered, and call the start position of
the tracing memory.

3. Press the RESTORE button.

The RESTORE button’s lamp flashes, and the start
position setting of the tracing memory can be changed.

The change mode is cancelled if the START/STOP
button is pressed at this point.

4. Press the RESTORE button again.

The pan/tilt head system starts performing the
operations entered in the tracing memory, and the
RESTORE button’s lamp stops flashing and comes on.
As with the data entry process, buttons No. 11 through
No. 30 serve as a general guideline for the time.

5. The tracing memory operations are changed.

Partial changes cannot be made to tracing memory
operations. Enter all the operations again starting from
the point where the change is made.

6. As soon as the lamp in button No. 11 goes off, the

buzzer sounds, and the tracing memory change is
completed.

1. Select the pan/tilt head system using the CONTROL/

PREVIEW MONITOR OUT SEL button.

2. Press the button in which the tracing memory data to be

recalled has been entered.
The pan/tilt head system is set to the start position
entered in the tracing memory.

3. After the pan/tilt head system has been set to the tracing

memory start position status and then stopped, press
the button in which the tracing memory data has been
entered again.
The pan/tilt head system now starts the operations
entered in the tracing memory.

 When the AW-PH350, AW-PH360 or AW-PH650

is used as the pan/tilt head, no operations will
be acknowledged even if the button in which the
tracing memory data has been entered is pressed
before the head is set to the start position status.
When using a pan/tilt head other than the AW-PH350,
AW-PH360 or the AW-PH650, the tracing operation
will again be performed from the position where the
button is pressed if the button in which the tracing
memory data has been entered is pressed before
the head is set to the start position status.
Therefore, the button in which the tracing memory
data has been entered must be pressed after the
pan/tilt head system has been set to the tracing
memory start position status and stopped.

 Press the START/STOP button to suspend the

recall of the data from tracing memory at any time.
This recall can also be suspended as soon as the
pan, tilt, zoom or focus operation has been initiated.

 The buzzer sounds when tracing memory data

recall is started or suspended and when the data
recall is completed.

Recalling tracing memory data

Making changes to the tracing memory

Operation
