3 Close the oven door to
the first opening position
(halfway). Then pull for-
ward and remove the door
from its seat.
4 Put the door on a soft
cloth on a stable surface.
5 Release the locking
system to remove the in-
ternal panel of glass.
90°
6 Turn the two fasteners
by 90° and remove them
from their seats.
1
2
7 Carefully lift (step 1)
and remove (step 2) the
panel of glass.
Clean the glass panel with water and soap. Dry the glass
panel carefully.
Installing the door and the glass panel
When you install the panel with a decorative frame, make
sure that the screen-printing zone looks to the inner side
of the door. Make sure that after the installation the sur-
face of the glass panel frame on the screen-printing zones
is not rough when you touch it.
Make sure that you install the internal panel of glass in the
seats correctly (refer to the illustration).
What to do if…
Warning! Refer to "Safety information" chapter.
Problem Possible cause Remedy
The appliance does not heat
up.
The appliance is deactivated. Activate the appliance.
The clock is not set. Set the clock.
The necessary settings are not set. Do a check of the settings.
The automatic switch-off is on. Refer to "Automatic switch-off".
The Child lock is on. Refer to "Deactivating the Child Lock".
33
