3
ASSEMBLY
Fitting the air outlet duct
This air conditioner is required to have the air outlet
duct fitted to an external opening to exhaust the hot air.
The duct can be extended from 390mm to 1500mm
long, however it is recommended to use the shortest
possible
length.
• Pull the end of the air outlet duct apart by several
turns
• Open the C-shape clamp from dosed position
• Insert the pulled apart and of the air outlet duet into
the exhaust outlet and dip the C-shape clamp to fit
the air outlet duct In position.
Prevent any bow or bend In the middle of the duct, as
this will trap hot exhaust air, which will radiate Into
the room and cause the unit to shut off automatically
(due to overheating).
IMPORTANT: The duct length hat been
specifically designed for this product. Do not replica
or lengthen the duct with attachments. If the venting
of the exhaust air is inhibited in any wary the unit may
over heart and shut off.
The location may be either a temporary or permanent
type depending on your requirement. If you wish to
frequently move the unit from room to room without
creating a permanent opening in a wall or window,
you can use the temporary location kite as described
below under temporary location.
If you wish to have a place set aside where you can
connect and operate the unit on a continuous basis you
can use the round connector, as described below under
permanent location.
