Panasonic NV-RZ1ENC - Инструкция (Страница 19)

1
2
3
m [CAMERA/OFF/VCR] [CAMERA]
(^mmm) 3t[vcR](^ii^) =
• ~.^isaeO ’ ”
• ^[sie
T j " ■■ (-+26)
■ littlBiteBi
4
m [CAMERA/OFFA/CR] [OFF] °
[<] BATTERY EJECT] m ' “
Attaching the Charged Battery
1 Insert the Battery with its top (so that the arrow
points upward) into the top Battery Holder.
2
Press the bottom of the Battery toward the
Movie Camera until it iocks with a click.
3
Set the [CAMERA/OFFA^CR] Switch to
[CAMERA] or [VCR].
•Turn the switch while pressing the button 0 .
•The Remaining Battery Operation Time can be
confirmed in the Finder.
• To ensure more precise indication of the remaining
battery power, attach a fully charged Battery.
• For details about the Remaining Battery Power
Indication, read “Checking the Remaining Battery
Power", (-► 26)
■ Removing the Battery
4
Set the [CAMERA/OFFAfCR] Switch to [OFF].
5
Hold the Battery firmly to prevent it from
dropping and pull it off while sliding the
[<] BATTERY EJECT] Lever in the direction of
the arrow.
24
