-fj
1.
(№Hi)
^ A ■^
j
T=-
s
’ ,i' "T’
t
(-♦20)
2. mm (№1^)
• if t^tz^'?[-№m.^:iflliO'']S;Aj.t^i|§i.fi "
{-►20, 24)
3.
{MPPti№)
1
[DC IN]
ii?L
■=
?L =
50/60Hz} -
JM
^±
H-£■ p { S ^ ^ f i i ^ ^ K ; 1
The 3 Types of Power Supplies
To try out the Movie Camera at home, we recommend that
you use the AC Adaptor 0.
1
. AC Adaptor (supplied)
•To use the Movie Camera indoors.
• To charge the Battery, {-+
20)
2
. Battery (supplied)
•To use the Movie Camera outdoors, and also indoors
when there is no AC mains socket nearby. (-►
20, 24)
3. Car Battery Charger (optional)
• To use the Movie Camera in a car.
Using the AC Adaptor as Power Supply Unit
1
Connect the DC Input Lead to the [DC IN]
Socket on the Movie Camera.
2
Connect the other end of the cable to the
[DC OUT] Socket on the AC Adaptor.
3
Connect the AC Mains Lead to the AC Adaptor
and to an AC mains socket.
The AC Adaptor features automatic universal voltage
adjustment (AC 100-240 V, 50/60 Hz), therefore, there is no
need for any manual voltage adjustment for use in other
countries.
18
