ENGLISH
Power Supply
pT| How to Use the AC Adaptor as Power
Supply Unit
Note:
When using the AC Adaptor to supply the Movie Camera
with power, do not attach the Battery Pack to the AC
Adaptor.
Connect the DC Input Cable to the [DC IN]
Socket on the Movie Camera.
1
2
3
4
Connect the other end of the cable to the
DC Output Socket on the AC Adaptor.
Connect the AC Mains Cable to the AC
Adaptor.
Connect the other end of the AC Mains
Cable to an AC mains socket.
|T| How to Use the Car Battery Cord
(optional)
Notes:
1. The Car Battery Cord can only be used with 12 V DC
negative-grounded vehicles.
2. Do not start the car engine while the Movie Camera is
powered by the car battery.
3. If the voltage drops suddenly, e.g. when the heater in
the car is turned on, the Movie Camera automatically
turns off to protect itself. Wait about 10 seconds
before turning it on again.
1
Start the engine and then plug the Car
Battery Cord into the cigarette iighter
socket
O-
2
Connect the other end of the cord to the
[DC IN] Socket on the Movie Camera.
m
mms.0
1
(
dc
iN] #
?Lo
2]
(ilPP##)
;±,B:
3.
S7P.S
«if?LOo
5Lo
62
