٢۶ ﻰﺳﺭﺎﻓ
١
[
ﺪﻳﺭﺍﺩ ﻪﮕﻧ
]
٢
<X’over HPF/LPF>
}
<Audio>
}
X’over HPF/LPF
Easy
Pro
٣
ﺪﻴﻨﻛ ﺏﺎﺨﺘﻧﺍ ﺍﺭ ﻢﻴﻈﻨﺗ ﺵﻭﺭ
}
.
[ Pro /Easy ]
۴
...
ﺩﻮﺷ ﺏﺎﺨﺘﻧﺍ ٣ ﻪﻠﺣﺮﻣ ﺭﺩ
“Easy”
ﺮﮔﺍ
HPF/LPF
Front
Full
cm/inch
ﻮﮔﺪﻨﻠﺑ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ ﺍﺭ
¢
/
4
.ﺪﻴﻫﺩ ﺭﺎﺸﻓ
[ * Subwoofer /Rear /Front ]
<Subwoofer On/Off>
یﺍﺮﺑ
<On>
ﻪﻛ ﯽﻣﺎﮕﻨﻫ ﻂﻘﻓ
*
(
٢٩ ﻪﺤﻔﺻ
)
.ﺩﻮﺷ ﯽﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ،ﺪﺷﺎﺑ ﻩﺪﺷ ﺏﺎﺨﺘﻧﺍ
ﺍﺭ ﻝﺮﺘﻨﻛ ﻪﺟﺭﺩ ،ﻮﮔﺪﻨﻠﺑ ﻩﺯﺍﺪﻧﺍ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ
.ﺪﻴﻧﺎﺧﺮﭽﺑ
: Rear /Front
/(4”) 10cm
/
[
ﻪﻴﻟﻭﺍ ﺖﻴﻌﺿﻭ
] Full
/(6-1/2”) 16cm /(5-1/4”) 13cm
/(7”) 18cm /
(
6-3/4”) 17cm
/(5x7”) 13x18cm /(4x6”) 10x15cm
/(6x9”) 15x23cm /(6x8”) 15x20cm
(7x10”) 18x25cm
: Subwoofer
/(8”) 20cm /(6-1/2”) 16cm /Full
/[
ﻪﻴﻟﻭﺍ ﺖﻴﻌﺿﻭ
] (10”) 25cm
(15” over) 38cm over /(12”) 30cm
،
[ inch /cm ]
یﺮﻴﮔ ﻩﺯﺍﺪﻧﺍ ﺪﺣﺍﻭ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ
.ﺪﻴﻫﺩ ﺭﺎﺸﻓ ﺍﺭ
∞ / 5
.ﺪﻴﻫﺩ ﺭﺎﺸﻓ ﺕﺎﻤﻴﻈﻨﺗ ﺪﻴﻳﺄﺗ یﺍﺮﺑ ﺍﺭ ﻝﺮﺘﻨﻛ ﻪﺟﺭﺩ
...
ﺩﻮﺷ ﺏﺎﺨﺘﻧﺍ ٣ ﻪﻠﺣﺮﻣ ﺭﺩ
“Pro”
ﺮﮔﺍ
HPF/LPF
Front
HPF Off
–18dB/Oct
ﻮﮔﺪﻨﻠﺑ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ ﺍﺭ
¢
/
4
ﺭﺎﺸﻓ
[ * Subwoofer /Rear /Front ]
.ﺪﻴﻫﺩ
<Subwoofer On/Off>
یﺍﺮﺑ
<On>
ﻪﻛ ﯽﻣﺎﮕﻨﻫ ﻂﻘﻓ
*
(
٢٩ ﻪﺤﻔﺻ
)
.ﺩﻮﺷ ﯽﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ،ﺪﺷﺎﺑ ﻩﺪﺷ ﺏﺎﺨﺘﻧﺍ
ﺍﺭ ﻝﺮﺘﻨﻛ ﻪﺟﺭﺩ ،ﺮﺘﻠﻴﻓ ﺲﻧﺎﻛﺮﻓ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ
.ﺪﻴﻧﺎﺧﺮﭽﺑ
: Rear /Front
ﺮﺘﻠﻴﻓ
: HPF 200Hz — HPF 30Hz
ﺲﻧﺎﻛﺮﻓ .ﺪﻨﻛ ﯽﻣ ﻝﺎﻌﻓ ﺍﺭ
(HPF) “
ﺱﺎﭘ یﺎﻫ
”
یﺎﻫﻮﮔﺪﻨﻠﺑ ﺯﺍ ﺮﺘﻠﻴﻓ ﺲﻧﺎﻛﺮﻓﺯﺍ ﺮﺗ ﻦﻴﻳﺎﭘ یﺎﻫ
.ﺪﻧﻮﺷ ﯽﻣ ﺮﺘﻠﻴﻓ ﺐﻘﻋ/ﻮﻠﺟ
ﺮﺘﻠﻴﻓ
: [
ﻪﻴﻟﻭﺍ ﺖﻴﻌﺿﻭ
] HPF Off
ﻝﺎﮕﻨﻴﺳ ﻪﻤﻫ
)
ﺪﻨﻛ ﯽﻣ ﻝﺎﻌﻓ ﺮﻴﻏ ﺍﺭ
“
ﺱﺎﭘ یﺎﻫ
”
ﯽﻣ ﻝﺎﺳﺭﺍ ﺐﻘﻋ ﺎﻳ ﻮﻠﺟ یﺎﻫﻮﮔﺪﻨﻠﺑ ﻪﺑ ﺎﻫ
.
(
ﺪﻧﻮﺷ
: Subwoofer
: LPF 200Hz — LPF 30Hz
ﺮﺘﻠﻴﻓ :
[ LPF 80Hz
:ﻪﻴﻟﻭﺍ ﺖﻴﻌﺿﻭ
]
￯ﺎﻫ ﺲﻧﺎﻛﺮﻓ .ﺪﻨﻛ ﯽﻣ ﻝﺎﻌﻓ ﺍﺭ
(LPF) “
ﺱﺎﭘ ﻮﻟ
”
ﺮﻓﻭﻭ ﺏﺎﺳ ﻪﺑ ﻩﺪﺷ ﺏﺎﺨﺘﻧﺍ ﺲﻧﺎﻛﺮﻓ ﺯﺍ ﺮﺘﻤﻛ
.ﺪﻧﻮﺷ ﻰﻣ ﻩﺩﺎﺘﺳﺮﻓ
ﺪﻨﻛ ﯽﻣ ﻝﺎﻌﻓ ﺮﻴﻏ ﺍﺭ
“
ﺱﺎﭘ ﻮﻟ
”
ﺮﺘﻠﻴﻓ
: LPF Off
ﺐﻘﻋ ﺎﻳ ﻮﻠﺟ یﺎﻫﻮﮔﺪﻨﻠﺑ ﻪﺑ ﺎﻫ ﻝﺎﮕﻨﻴﺳ ﻪﻤﻫ
)
.
(
ﺪﻧﻮﺷ ﯽﻣ ﻝﺎﺳﺭﺍ
LPF/HPF
ﺖﻴﻔﻴﻛ ﺏﺎﺨﺘﻧﺍ یﺍﺮﺑ
[ –24dB/oct /–18dB/oct /–12dB/oct ]
.ﺪﻴﻫﺩ ﺭﺎﺸﻓ ﺍﺭ
∞ / 5
:ﻪﻴﻟﻭﺍ ﺖﻴﻌﺿﻭ
]
،
–18dB/oct : Rear /Front
[ –12dB/oct : Subwoofer
ﺭﺎﺸﻓ ﺕﺎﻤﻴﻈﻨﺗ ﺪﻴﻳﺄﺗ یﺍﺮﺑ ﺍﺭ ﻝﺮﺘﻨﻛ ﻪﺟﺭﺩ
.ﺪﻴﻫﺩ
X’over HPF/LPF—“
ﺱﺎﭘ ﻮﻟ
”/“
ﺱﺎﭘ یﺎﻫ
”
ﺮﺘﻠﻴﻓ ﻊﻃﺎﻘﺗ ﻢﻴﻈﻨﺗ
