17
Operation
04:28
1 2 3 4 5 6 7 8 9 10
1. Touch to fast forward and fast rewind.
2. Volume indicator.
3. Touch to select previous/next track/title.
4. Clock.
5. Touch to pause/resume playback.
6. Touch to go to setup menu.
7. Touch to stop playback.
8. Return to Main menu.
9. Touch to go to DVD setup menu.
10. Touch to close the menu.
When the image is in full-screen mode,
touch left upper corner of the screen to go
back to the DVD interface.
Manufacturer guarantees regular
playback of licensed discs only. Some AVI files
cannot be played due to their parameters and
recording conditions. Video files more than 2 Gb
having AVI extension can be played partially.
File disc/CD/USB/SD/MMC interface
When an MP3/CD/USB/SD/MMC is played,
following touchable menu will be displayed:
1 2 3 4
1. Current storage indication.
2. Contents list. Touch an item (file/folder) to
enter or start it.
3. Current playback information (track
number/total tracks/total time/elapsed time/
bitrate etc., depending on the format).
4. Content navigation buttons.
Insert/eject USB or Memory card
Connect a USB drive to the USB connector
of this unit. It will automatically switch to USB
mode and start to read the contents of the
USB. To eject the USB drive from this unit,
switch to another mode and disconnect the
USB from the USB wire connector.
To connect a memory card to this unit,
detach the front panel and insert the memory
card into the slot. Attach the front panel. The
unit will automatically switch to SD mode and
start to read the contents of the memory card.
To eject the memory card, switch the unit to
another mode, then open the front panel and
push the card until it pops out.
USB capacity supported: up to 8 Gb.
For correct and satisfactory operation, licensed
SD/MMC memory cards of famous brands
should be used with this unit. Avoid using
memory cards of unknown brands. Capacity:
up to 8 Gb.
Selecting tracks
For DVD/MP3: Press / buttons on the
RC or on the panel to skip to the previous or
next chapter.
For VCD/CD: Press button on the RC
or on the panel to skip to the beginning of the
current chapter. Press twice
button on
the RC or on the panel to skip to the previous
chapter. Press
button on the RC or on the
panel to skip to the next chapter.
Pause/Stop the playback
Press button on the RC or /BND button
on the panel to switch between play and pause.
Press button on the RC or / button
on the panel to stop playback. If you press
