11
Operation
Remote controller (RC)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1. AF/EQ button
2. PWR button
3. GOTO button
4. BAND/TITLE button
5. Number buttons
6. AMS/MENU button
7. LOC/SUB-T button
8. LEFT cursor button
9. ST/AUDIO button
10. OSD button
11. PTY/ANGLE button
12.
/ button
13. button
14. ZOOM button
15. PROG button
16. P/N/ button
17. VOL- button
18. button
19. TA/LOUD button
20. MODE button
21. UP cursor button
22. CLEAR button
23. ENTER button
24. RIGHT cursor button
25. DOWN cursor button
26. SETUP button
27.
/ button
28. button
29. / button
30. RPT button
31. RDM button
32. SEL button
33. VOL+ button
Changing the battery
1. Press the catch and at the same time pull
out the battery tray.
2. Insert the 1 lithium battery, type CR2025
(3 V) battery with the stamped (+) mark facing
upward. Insert the battery tray into the remote
controller.
• Store the battery where children
cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.
• Do not recharge, short, disassemble or
heat the battery or dispose it in a fire.
• Do not expose or bring into contact the
battery with other metallic materials. Doing this
may cause the battery to give off heat, crack or
start a fire.
• When throwing away or saving the battery,
wrap it in tape and insulate; otherwise, the
battery may give off heat, crack or start a fire.
• Please direct the Remote controller to the
IR sensor of the front panel.
