14
Operation
correspondng band.
• Key Beep: Select ON or OFF, the default
setting is ON. It means when you press the
buttons, they are sounded.
• Rever Pola (Reverse Polarity): The signal
is +12V when you back a car, select BATTERY
on the monitor; if the signal is 0 V, select
GROUND.
• TA Volume: You can select LOW,
NORMAL or HIGH TA volume.
Radio operation
User interface of Radio mode
When the unit is switched to Radio mode,
the below touchable user interface will be
displayed on the display.
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 17
1. Current band indicator.
2. Touch to go to RDS page.
3. Volume level.
4. Current frequency.
5. Current channel number.
6. Clock.
7. Touch to go to setup menu.
8. Return to Main menu.
9, 11. Touch repeatedly to change frequency
step by step. Touch and hold for automatic
search of the nearest station.
10. Touch to scan the current band
channels. Touch and hold for automatic search
and saving.
11. Touch to select bands.
13, 14. Touch to select previous/next saved
station.
15. Touch to select mono/stereo reception.
16. Station list. Touch an item call the
station. Touch and hold to save the current
frequency in the preset position.
17. Touch to switch between local and
distant station receprion.
Band selection
Press BAND/TITLE button on the RC or /
BND button on the panel to switch to the bands
in the following order: FM1 - FM2 - FM3 – FM4
(OIRT) - AM1 - AM2.
Manual/automatic tuning
• Manual tuning: Press / buttons on
the RC repeatedly to change the frequency
upward or downward step by step.
• Automatic tuning: Press and hold /
buttons on the RC to start automatic seeking for
an available radio station downward or upward.
After being found the station will be played.
Manual storing of stations
Find the needed frequency, press and hold a
number button (1~6) under which you want to
store the station. The station will be stored. To
call a stored station, press the corresponding
number button.
Scanning/memorizing stations
automatically
In radio mode, you can press AMS/MENU
button on the RC or AMS button on the panel
to scan for several seconds each station
stored in number positions. You can press the
corresponding number buttons, AMS/MENU
button on the RC or AMS button on the panel
when your desired station is on. And it starts
playing that station.
Press and hold AMS/MENU button on
the RC or AMS button on the panel; it will
activate automatic storing function. The tuner
automatically finds a station and stores it in
number positions.
