KEY DEFINITIONS
REMOTE TRANSMITTER: Transmits the radio signal
to the Collar Receiver. It is waterproof and can be
submerged in water to a depth of 7.6 m.
INTENSITY DIAL: Provides multiple levels of static
stimulation so you can match the correction to your
dog’s temperament.
TRANSMITTER INDICATOR LIGHT: Indicates
that a button is pressed and also serves as a
low-battery indicator.
TOGGLE SWITCH: This switch is factory-set so that the
Remote Transmitter can control two Collar Receivers.
UPPER BUTTON: This button is factory-set to deliver
continuous static stimulation.
LOWER BUTTON: This button is factory-set to deliver
momentary static stimulation, or a “Nick”.
SIDE BUTTON: This button is factory-set to deliver a
tone without static stimulation.
CHARGING JACK: For connecting the charger.
Although the Remote Transmitter is waterproof without
it, keep the cover in place when not charging to keep
debris out of the opening.
COLLAR RECEIVER: Receives the radio signal from the
Remote Transmitter and delivers the static, vibration, or tone
stimulation for correcting or cueing your dog. It is waterproof
and can be submerged in water to a depth of 7.6 m.
RECEIVER INDICATOR LIGHT: Indicates when the
Collar Receiver has been turned on or off and serves as a
low-battery indicator.
CONTACT POINTS: The contacts through which the
Collar Receiver delivers static stimulation.
ON/OFF BUTTON: Momentarily pressing and releasing
this button turns the Collar Receiver on and off.
THE COLLAR RECEIVER IS CAPABLE OF DELIVERING FOUR TYPES OF STIMULATION:
CONTINUOUS: You control both when and how long stimulation is delivered, up to a maximum of 10
seconds. After 10 seconds, the stimulation will “time out” and the Transmitter button needs to be released
and then pressed again before additional stimulation can be delivered.
MOMENTARY (NICK): Static stimulation is delivered for 1/10 of a second, regardless of how long the
button is pressed.
TONE: The Collar Receiver will make a rapid beeping noise when a Tone button is pressed, up to a maximum
of 10 seconds.
VIBRATION (VIBE): The Collar Receiver will vibrate when a Vibration button is pressed, up to a maximum
of 10 seconds.
TRANSMITTER
INDICATOR LIGHT
INTENSITY
DIAL
TRANSMITTER
ANTENNA
SIDE
BUTTON
LOWER
BUTTON
UPPER
BUTTON
CHARGING
JACK
CONTACT POINTS
RECEIVER
INDICATOR
LIGHT
ON/OFF
BUTTON
TOGGLE
SWITCH
