70
9 Whisks: left/right with toothed bar
10 Liquidising dics
11 Mixing attachment (The metal cap is available only in the
“Silver Line” series)
12 Cup
13 Mixing cup
14 Doser
15 Lid
16 Knife cup
17 Stand
18 Head
19 Grip knob
20 Fastening button
21 Rotating bowl
22 Blade
ZELMER mixers types (Fig. B)
basic mixer equipment
additional equipment, which you can buy in shops
Device description
The mixer has 5 speed positions. The lever is used to set
●
up the particular rotation speed according to the numbers:
0, 1, 2, 3, 4, and 5 on pusher button, which helps to remove
(push out) the mixers or whisks from the mixer motor part.
Additionally, the drive has
●
„turbo” button which helps to
get the maximum rotation speed immediately, regardless
the speed set with the lever. Such buttons are placed
both on the right and left sides of the casing intended for
the convenience of both left and right-handed users. The
„turbo” button is automatically blocked in „0” position.
There are 2 sockets (holes), for whisks or mixers
●
assembling, placed on the bottom of the motor part.
The insert handle, placed on the top of the motor part, is
●
made of the material increasing the comfort of holding the
mixer motor part.
There is a hole for mixing adapter or mixing cup assembling
●
at the back of motor casing. The hole is covered with
a mobile cover.
There is a clamp and a fastener in the lower part of motor
●
casing, for power cord winding around the motor casing.
Mixer start-up and position setting
(rotation speed) (Fig. C)
1 Place the ON/OFF switch in the „0” position - the
leftmost position. Install the selected tool.
2 Plug in the appliance.
3 Switch on the appliance by sliding the switch to the right.
4 If you want to increase the rotation shift the lever in
position „5” direction, choose the desired rotation speed.
5 In order to increase the rotation immediately, regardless
set speed, press and hold one of „turbo” buttons (on the
right or left side of the casing).
6 When you want to return to the previously selected
speed release „turbo” button.
Preparing for operations
Operation with whisks or mixers (Fig. D)
The whisks are intended to whipping eggs white foam,
●
cream, rubbing yolks with sugar, cream and pancakes or
omelettes dough preparation.
The mixers are intended to work the rubbed dough, yeast
●
dough, cheeses cakes, imbirbread cakes, etc.
The whisks and mixers shall be assembled in sockets on
●
the bottom of the robot.
1 Press until you feel the refusal – when the clamps get
fastened.
When assembled improperly, the parts fall apart during
operation.
2
Insert the mixer or whisk with toothed bar into the socket
marked with a star.
The reverse assembling of the mixers can cause lifting
up the dough (taking the dough out of bowl).
The level of products inside the bowl should not
exceed the hight of mixers or whisks working part (L).
Operation with liquidising disc (Fig. E)
Liquidizing disc is used for liquidizing boiled fruit and
●
vegetables such as: carrots, potatoes, tomatoes, apples
through the sieve. It partly replaces the function of the
mixing adapter.
1 Insert the liquidizing disc on the whisk with toothed bar
from the bottom side.
2 Insert the whisk into the socket marked with a star.
Cup (12)
Made of transparent material is used as a container when
mixing adapter is used.
Operation with mixing adapter (Fig. F)
You can use the mixing adapter for:
mixing liquids,
●
crumbling boiled vegetables and raw, soft fruit,
●
preparing different mayonnaise and pastes,
●
preparing soups for infants.
●
crushing ice (metal adapter only).
●
You can assemble the adapter after moving the cover.
1 Gently press the bolt and slide towards the direction
shown in the figure.
1 cm L 1 cm L
