Part 7z
Gas
Your cooker can operate both
Natural Gas and LPG. You con
convert by changing the gas
source and the top burner, oven
and g r i l l i n j e c t o r s . T h e
replacement procedure of the
injectors ore explained below.
Call authorized Service for gas
convertion.
Replacement of the top
burner injector
Take off the burner head
and burner cop before
storting this procedure.
Then:
7. Remove the injector
inside the top burner with
a suitable bit. Later, install
the new injector by covering
the injector threads
with leakage
preventing
Fhme failure
~ ^ device
material.
spark plug
€onver§ion
In models with Removal of the control panel
Reduced Tap Flow
In models with removal of the
control panel
7. Open the front door.
2. Unscrew the two screws of the control
panel and take the control panel bottom
sheet.
3. Release the control panel from the two
notches at the top, slightly pull it to the
bottom front and keep it free with its cobles
connected.
Ignite the burner that should be adjusted,
turn the knob to the reduced position, pull
and take the knob o f f .
4. With a screwdriver, moke the top
reduced flow adjustment from the injector
that is on the gas top (only the head is
visible with the bolt shape).
It is s u f f i c i e n t to tight to screw
completely, in butone/propane gas.
For the natural gas, you should turn the
screw counter-clockwise
once. The normal length of a straight
flame in the reduced position
/7
should be 6 - 7mm.
If the flame is higher than the desired
position, turn the screw clockwise. If its
smaller to the opposite.
For the lost control of the burning of the
cooker, bring the cooker high-flame and
reduced positions and check whether the
flame is on or o f f .
