4.2 Operating the hot plates
Hotplate control position
Application
Corresponding Cooking Values
1
Warming Simmering Cooking-Frying-Boiling
A rapid heating hotplate is denoted by a red spot in
the centre of the hotplate:
Hoiplaie operaiing knobs
The knobs for the hob can be rotated in either direction
to provide fully variable heat control. When any one
of the hotplates is on,
the red Indicator light
on the control panel will be on»
In order to switch the hotplate
OFF
turn the corresponding
knob to the 0 (zero) position. Knobs of the hotplates
can be turned both clockwise and counter-clockwise
directions.
Check that all the cooker controls have
been switched oH after use»
Adjust the hotplates to mid position (3) and leave on
for approximately 8 minutes in order to burn off the
protective coating on the hotplates. Do not place any
pans or other cooking utensil on the hotplates during
this process. Fumes will be emitted during the above
operation but this is quite normal.
Good Qualify Pans
Use only good quality pans having a stable bottom as shown below. This
results in the maximum use of energy.
Use pans for the correct diameter
only. If the pan is too small energy
is wasted.
Do not place pans with wet
bases or pan lids particulary wet
lids on the hotplates damage could
occur and safety problem will be
experienced.
Hotplate diameter
¡mm)
0 145 mm
Suggested diameter
of the pan (mm)
----- ► 150-170
J=
Drying
the
----
1
hotplafes
(max 5 min)
When cool;
Clean off solid hotplates with a damp cloth and a little domestic
cleaning cream. After cleaning, dry solid hotplates by switching on for
a short time. Apply a thin coat of cooking oil from to time.
When wiping the hotplates with a damp cloth follow the circular
grooved pattern on the hotplate.
8
