P a r t 9 : G a s c o n v e r s i o n
Your cooker can operate both
Natural Gas and LPG. You can
convert by changing the gas
source and the top burner, oven
and
grill
injectors.
The
replacement procedure of the
injectors are explained below.
Call authorized Service for gas
convertion.
Replacement of the
top burner injector
Take off the burner head and
burner cap before starting this
procedure. Then:
1.
Remove the injector inside
the top burner with a suitable
bit. Later, install the new
injector by covering the injector
threads with leakage
preventing
material.
Flame failure
device
spark plug
Reduced Tap Flow
Removal of the control panel
1.
Open the front door.
2.
Unscrew the two screws of the control
panel and take the control panel bottom
sheet.
3.
Release the control panel from the
two notches at the top, slightly pull it
to the bottom front and keep it free
with its cables connected.
Ignite
the
burner
that should
be
adjusted, turn the knob to the reduced
position, pull and take the knob off.
4.
With a screwdriver, make the tap
reduced flow adjustment from the
injector that is on the gas tap (only the
head is visible with the bolt shape).
It is sufficient to tight to screw
completely,
in
butane/propane
gas.
For the natural gas, you should turn the
screw
counter-clockwise
once.
The
normal length of a straight flame in the
reduced position should be 6 - 7mm.
If the flame is higher than the desired
position, turn the screw clockwise. If its
smaller to the opposite.
For the last control of the burning of
the cooker, bring the cooker high-flame
and
reduced
positions
and
check
whether the flame is on or off.
Injector.
Burner
26
