Oven heating control knob
This knob is used together with the "function
selection" knob. Select the desired stage with the
"function selection" knob. Then rotate the "oven
heating control" knob clockwise. The lamp and
the heating elements in conjuction with the stage
you have selected, or the fan will come on line.
The temperature in the oven shall be sensed by
the thermostat. The thermostat switches off the
heating element and the thermostat light when
the set temperature level is reached inside the oven.
When the temperature falls below thermostat
comes back on line and the thermostat light
illuminates. This way, the set temperature level is
maintained throughout the cooking period.
Function selection knob
This knob allows you to select functions and carry
out checks. The functions and their stages are
explained below. In order to operate the stages,
you need to bring the "function selection" knob
together with the"oven heating control" knob
to the desired temperature degree and adjust the
timer if there is. If your cooker has timer; refer
to the description of timer usage.
5.4 Operating the ovens- controlled
The stages of the function selection
knob for conventional ovens
by two knobs
Oven lamp light on. The heating elements
are out of operation.
I — I Upper and lower heating elements are on.
i—i It provides to cook the both sides of the
meal at the same level.
□ Lower heater is on.
You can use this position, if you want to
have the bottom side of your meal cooked
better.
□ Upper heater is on. You can use this
position, if you want to have the top side
of your meal cooked better.
Means only the grill heater is on.
You must bring to the heating control
knob to the maximum temperature.
Burning off the protective coating process.
In order to burn off the protective coating remove shelves and baking
tray by turning your oven to 250°C in S position for to 30 minute
periods without putting anything into it.
You must ensure this operation is conducted in a wall ventilated area.
The stages of the function selection
knob for conventional ovens
□
Upper and lower heating elements are on.
It provides to cook the both sides of the
meal at the same level.
Lower heater is on.
□ You can use this position, if you want to
have the bottom side of your meal cooked
better.
□ Upper heater is on. You can use this
position, if you want to have the top side
of your meal cooked better.
Means only the grill heater is on.
You must bring to the heating control
knob to the maximum temperature.
Means, both grill heater and rôtisserie
function are on.
You must bring to the heating control
knob to the maximum temperature.
17
