Panasonic NV-VX22EN - Инструкция (Страница 33)

1 [й]:И;fi!i[AOPEN]ffi,I^BtSnÌ?şi/Tv,
)IÌ-;«B"aP/TÌ^iÈl^ÌTrfTW90“ o
■ gsr^-;t^aP^Tv^iitiRt
r#o
7Zo
Ì£lI§l_bòi]^®si:fc¥^Hto ^rfn, ì^^SJìilE^iS^a#,
• nm№M^
S0i?ÌÉ^„
36
Using the LCD Monitor
Improved LCD backlight transmission makes the picture
extra bright. In addition, special coating of the LCD’s
surface diffuses the light from outside to minimize light
reflection, so the picture has vivid colours and is easy to
see.
■ Opening the LCD Monitor
1 Siide the [ A OPEN] Lever to the ieft and
simultaneously open the LCD Monitor
in the direction of the arrow
approximately 90°.
■ Closing the LCD Monitor
2 Turn the LCD Monitor back toward the
Movie Camera body until it locks with a
click.
• Return the LCD Monitor to its vertical position before
closing it, Also, make sure that the Cassette
Compartment is securely closed before closing the
LCD Monitor.
•Opening the LCD Monitor automatically turns the
Finder off. However, when you turn the LCD Monitor so
that is faces forward, the Finder turns on again.
• Extremely high precision technology is employed in
producing the LCD Monitor. The result is more than
99.99 % effective pixels with a mere 0.01 % of the
pixels inactive or always lit.
•When the Movie Camera is very cold when turning it
on, the picture on the LCD Monitor is darker than
normally. However, as it reaches normal temperature, it
regains its normal brightness.
•To remove fingerprints, wipe the LCD Monitor with the
supplied Cleaning Tissue or a similar soft cloth.
• Do not expose the LCD Monitor to direct sunlight. When
sunlight falls onto the LCD Monitor, it may be difficult to
view the picture.
• Do not apply any pressure to the surface of the LCD
Monitor or subject it to strong shocks.
• Before transporting the Movie Camera, securely close
the LCD Monitor.
