Panasonic NV-VX22EN - Инструкция (Страница 21)

SilJ^io
mmmmmmmMo
• 'Mmmm^, Rmmmmnmm
mm^j¥.o
3 ftjs[POWER] rjsiifi,
'M-o
ftitiJiBATTERY EJECT]«, lliatfi
ENGLISH
Attaching the Charged Battery
1 Insert the Battery with its top (the end
with the Charge Confirmation Marker)
into the top Battery Hoider.
2 Press the bottom of the Battery toward
the Movie Camera untii it iocks with a
dick.
•The remaining battery power can be confirmed
with the Remaining Battery Power Indication O
displayed on the LCD Monitor.
►After attaching the Battery, the Remaining
Battery Power Indication bhefiy indicates a fully
charged Battery regardless of the actual
charging condition. After a few seconds, it
indicates the
actual remaining battery power.
►When the Battery is exhausted, the [ ^ ]
Indication flashes and the Movie Camera
automatically turns off.
■ Removing the Battery
3 Turn in the [POWER] Switch to turn the
Movie Camera off.
4 Hold the Battery firmly to prevent it
from dropping and pull it off while
sliding the [BATTERY EJECT] Lever in
the direction of the arrow.
24
