English - 0
Setting the PC
➢
Preset to the PC mode by pressing the SOURCE button.
1 Press the MENU button to display the menu.
 Press the ▲ or ▼ button to select Picture, then press the
ENTER button.
 Select the required option by pressing the ▲ or ▼ button,
then press the ENTER button.
4 When you are satisfied with your setting, press the ENTER
button.
5 Press the EXIT button to exit.
 Auto Adjustment :
Auto adjustment allows the PC screen to self-adjust to the
incoming PC video signal.
The values of fine, coarse and position are adjusted
automatically.
Easy Setting
1 Press the TOOLS button on the remote control.
 Press the ▲ or ▼ button to select Auto Adjustment, then
press the ENTER button.
 Screen: Coarse/Fine/Position/Image Reset
- Coarse/Fine
The purpose of picture quality adjustment is to remove or
reduce picture noise.
If the noise is not removed by Fine-tuning alone, then adjust
the frequency as best as possible (coarse) and Fine-tune
again.
After the noise has been reduced, re-adjust the picture so that
it is aligned on the center of screen.
1 Press the ▲ or ▼ button to select Coarse or Fine, then
press the ENTER button.
 Press the ◄ or ► button to adjust the screen quality,
vertical stripes may appear or the picture may be blurry.
Press the ENTER button.
- Position
Adjust the PC’s screen positioning if it does not fit the TV
screen.
1 Adjust the position by pressing the ▲/▼/◄/► button.
 Press the ENTER button.
- Image Reset
You can replace all image settings with the factory default
values.
Move Enter Return
Coarse 50
Fine
Position 
Image Reset 
Screen T V
Move Enter Return
Position T V
Auto Adjustment in Progress
Please wait.
Image Reset is completed.
OK
Move Enter Return
Mode : Standard 
Cell Light
Contrast 0
Brightness 45
Sharpness 50
Auto Adjustment 
Screen 
Detailed Settings 
 More
Picture T V
Tools
Anynet+ (HDMI-CEC)
Picture Mode Standard
Sound Mode Custom
Sleep Timer Off
SRS TS XT Off
Energy Saving Off
PIP
Auto Adjustment
Move Enter Exit
