инструкция по эксплуатации станка JET мод.JRD-1100R
30
14 OL2 Over Load Relay RH 18/1.7 For 380V~460V 1
15 PB1 Emg.Push Button Switch SBT-307 Standard 1
16 SS1 Selector Switch ST302 Standard 1
17 SS2 Selector Switch SN1021 Standard 1
18 SS3 Cross Switch 3 Joint UP1A Down1A
Left1A1B Right1A1B Standard 1
19 SS4 Pole Reversing Switch A441 CA10 Standard 1
20 LS1 Limit Switch MJ2-1308R Standard 1
21 LS2 Limit Switch MJ2-1308 Standard 1
22 LS3 Limit Switch MJ2-1308 Standard 1
23 LS4 Limit Switch AZ 7311 Standard 1
24 WL Work Lamp FS51441 Standard 1
25 PL Pilot Light SP-301110V(R) Standard 1
26 PL Pilot Light SP-301110V(W) Standard 1
27 Amp Meter S065 30A For 200V~230V 1
28 Amp Meter S065 20A For 380V~460V 1
29 Coolant Pump Motor 1/8HP/2P/3PH L: 130mm Standard 1
30 Main Motor Vertical
3HP/1.5HP4P/8P Standard 1
NO Symbol Name Specification Refer Q'ty
31 Elevating Motor Horizontal 1HP/4P/3PH Standard 1
32 M1 Magnetic Contact CN11 3a1b 24V Optional 1
33 M4 Magnetic Contact CN11 3a1b 24V Optional 1
34 M5 Magnetic Contact CN11 3a1b 24V Optional 1
35 M0 Magnetic Contact CN11 3a1b 24V Optional 1
36 M2 Magnetic Contact CN18 24V Optional 1
37 M3 Magnetic Contact CN18 24V Optional 1
38 FU Fuse Seat 3P For U.S.A 1
39 FU Fuse Seat 1P For U.S.A 1
40 FU Fuse ONE TIME 5A For U.S.A 1
41 FU Fuse ONE TIME 40A For U.S.A 3
42 FU Fuse Seat 10*38 For Europe 4
43 FU Fuse 10*38 2A For Europe 1
44 FU Fuse 10*38 20A For Europe 3
45 Pilot Light YK30O 24V(R) Optional 1
46 Pilot Light YK30O 24V(W) Optional 1
47 TR Transformer Once 0.220.380 Twice
0.24.110 Optional 1
48 Safety Switch XF 163B Optional 1
