Function Description
Func
tion D
es
c
ript
ion
E
NG
Sleep Timer
When your TV is Running, start sleep function by setting
Sleep Timer in any case. This function allows you to power off
the TV within a period of time. Currently the supported time
period are: Off,10 Mins, 20 Mins,30Mins, 60Mins, 90 Mins,
120 Mins, 180 Mins, 240 Mins,
Hearing impaired
This function offers a subtitle such as a “stroke on the door” or
“the bell starts to ring” for the current scene in case that the
user is weak in hearing.
Auto Power Off
When your TV is Running, start Auto Power Off function by
setting Auto Power Off Timer in any case. This function
allows you to power off the TV within a period of time.
Currently the supported time period are: Off, 1 Hours,2
Hours,4 Hours
CI Info
It is only available in DTV source when PVR is not playing.
Please prefer to Chapter 6 section 2 CI Setup for further
information about the function of Cl.
NOTE:CI info The functions of the parts not
change please in kind prevail
Setup Menu
Press MENU button to display the main menu.
Press ENTER/RIGHT button to select Setup Menu in the main menu. then press ENTER/RIGHT button to enter
1. Press UP/DOWN button to select the option that you want to adjust in the Setup menu.
2. Press ENTER/RIGHT button to enter, then press LEFT/RIGHT button to adjust.
3. After finishing your adjustments Press MENU/ENTER button to save and return back to the previous menu
OSD Timer
Set up OSD Timer which means how long the menus will exist. The optional periods are 5, 10, 15, 20, 25, 30 Seconds and
Never
Auto SCART
Switch for Auto SCART function.
PC Setup
It is only available in PC source.
Auto Adjust: Auto Adjust the H Position, V Position, Phase, Clock
H Position: Manually adjust H Position
V Position: Manually adjust V Position
Phase: Manually adjust Phase
Clock: Manually adjust Clock
Blue Screen
It is not available in PC, DTV source or when it is not movie mode
in multimedia source. In TV source, if there is no signal and Blue
Screen is Off, it will show snow; if there is no signal and Blue
Screen is On, it will show blue screen When the reset is complete, it will enter the Auto
Installation settings page.
First, it will show a page to user to confirm.
Reset to Setting
If the Lock Channel is On in Feature Menu/Lock , it needs to enter
the password to enter the Reset. It will Reset System Setting and
Database. Software Upgrade
Software upgrade by bin code. Put The bin code into the
root directory of the media and media plugged into the
TV‘s USB interface, press ENTER key to upgrade. Don’t
power off during the upgrading process. The system will
restarts when the upgrading process is done.
11
