jPart 6: Operating
* Preheat the grill at H (grill setting) for
approximately 5 minutes.
* For multifunction ovens,
set the "function
selection" knob to S orH and the "oven
heating control" knob to maximum
temperature.
••The indicator light will illuminate to show
that the grill has been switched on.
•■ Apply oil on the grill shelf to prevent meat
from sticking on the bars.
Using the Knob Heat Shield housing
into Oven Door (for suitable models)
WARNING!
Do not grill when the front
door is closed. Otherwise, oven parts may
be damaged. After preheating, keep the
front door half-open during grilling.
In order to prevent the knobs of the control
panel from heating up, center the knob
shield plate between the front cover and
the oven housing without leaving any
gap.
the grill and rôtisserie function
If your cooker has rôtisserie function
•
Locate a tray to one of the bottom shelves in
order to collect to oils and for easy cleaning put
some water in it.
• Ensure the food is correctly positioned under
the grill element.
• Food which requires browning only should be
placed under the hot grill, either in the grill pan,
or on the floor of the grill compartment,
according to the depth of the dish. The grill pan
wire grid can be removed.
• Do not line the grill pan with aluminium foil
as the increase in heat could create a fire hazard.
Using the Knob Heat Shield housing
into Oven Body (for suitable models)
WARNING
: After preheating,
keep
the front door fully open during
grilling.
In order to prevent the knobs
of the control panel from heating up,
the knob heat shield plate must be placed
in the housing where the bottom of the
control panel shown in the figure.
N
Control panel
Knob heat shield
Rôtisserie motor can be rotated in clockwise
or counter-clockwise directions.
* After operating your oven
in
grill position,
locate the chicken to the rôtisserie spit, and
insert the spit to the rôtisserie spit housing.
Attention:
* While performing the
rôtisserie function, do not forget to use the
knob heat shield correctly and keep the
oven door half open or fully open depending
upon the knob heat shield model you use.
Grill n
Shelf
position.
Cooking
duration
(min.)
Lamb
4-5
12-15
Lamb chops
4-5
12-15
Beef
4-5
15-25 |1]
Veal chops
4-5
15-25 HI
Veal
4-5
15-25 |1]
Fronf
door
20
(1) Depending on the thickness
•- Do not allow children to sit or stand
on the oven door when the
door is open.
Accessible part may become
hot when the grill is in use, children should
be kept away
