Partsidentification















a
c
d
b
b
e
f 








Front Back









    

A Mainbody
1 Protective cap
2 System outer foil
3 Foil frame
4 Foil frame release buttons
5 Finger rest
6 Power switch
7 Lock ring
8 Lamp display
a. Used time lamp
b. Battery capacity lamp
c. Shaving sensor lamp
( )
d. Clean lamp
e. Foil/blade check lamp
f. Charge status lamp ( )
9 Appliance socket
 Outer foil section
 System outer foil release
buttons
 Inner blades
 Trimmer
 Trimmer handle
 Main body rear terminals
B Self-cleaningrecharger
 Charging terminals
 Cleaning liquid unit
removal button
 Intake port
 Self‑cleaning recharger
socket
 Lock release lever
 Cleaning liquid filter
 Water maximum line
 Cleaning liquid unit
 STATUS lamp
 LOW lamp
 CLEAN lamp
 DRY lamp
 SELECT button
C ACadaptor(RE7-59)
 Adaptor
 Power plug
 Cord
 Appliance plug
Accessories
D
Travelcase
E Cleaningbrush
F Oil
G Specialdetergent
(Detergent)
