Installation Instructions LSA/LTA Series
3
DIMENSIONS
LTA
DIMENSION: [MILLIMETERS]
INCHES
1.00 25.4
.34 8.6
1.44 36.6
2.18 55.3
.57 14.4
34.53 877.1
2.00 50.8
12.00 304.8
MINIMUM UPRIGHT
SPACING IS 12"
RAILS CAN BE SLID LEFT
OR RIGHT FOR OFFSET
13.23 336
20.54 521.7
12°
.93 23.6
5.29 134.5
7.00 177.8
1.00 25.4
21.00 533.4
.53 13.5
.32 8.1
0
.49 12.5
.98 25
1.48 37.5
1.97 50
2.46 62.5
2.95 75
3.44 87.5
3.94 100
4.43 112.5
4.92 125
5.41 137.5
5.91
NOTES:
MAX MOUNTING PATTERN IS 30.6" (777.2 mm) WITHOUT REVERSING UPRIGHTS.
12.00 304.8 1.44 36.6
2.19 55.7
34.57 878.1
1.00 25.4
.57 14.4
1.52 38.5
MINIMUM UPRIGHT
SPACING IS 12"
1.96 49.8
13.23 336
21.28 540.4
3.44 87.5
.32 8.1
.59 15.1
.87 22.1
0
.49 12.5
.98 25
1.48 37.5
1.97 50
2.46 62.5
2.95 75
3.44 87.5
.49 12.5
3.94 100
4.43 112.5
4.92 125
5.41 137.5
5.91 150
6.40 162.5
6.89 175
7.38 187.5
7.87 200
8.37 212.5
8.86
8.37 212.5
9.97 253.2
NOTES:
MAX MOUNTING PATTERN IS 31.8"[807.7mm] WITHOUT REVERSING UPRIGHTS. 1.
MAX MOUNTING PATTERN IS 34.3"[871.2mm] WITH REVERSING UPRIGHTS. 2.
FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK 3.
ENGAGEMENT IS .56"[14.2mm].
MOUNT RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET APPLICATIONS. 4.
MOUNT IS 1.96"[49.8mm] DEEP WHEN FLAT TO WALL.
LSA
DIMENSION: [MILLIMETERS]
INCHES
