Panasonic CS-PA7GKD - Инструкция (Страница 5)


E
NGLISH
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
• Use the ON timer to turn on the air conditioner at the desired time.
This will give you a cooling environment, e.g. when you return from
work or wake up.
• When the ON timer is set, operation will start 15 minutes before
the actual set time in cooling operation and 30 minutes in heating
operation.
• Use the OFF timer to stop the air conditioner operation at the
desired time. This can save electricity while you are going out or
sleeping.
• The timer indicator of the indoor unit will light up during the timer
operation.
• If you press operation button during the timer setting
operation, timer setting will be cancelled.
• When a power failure occurs, the timer setting will be cancelled.
Once power is resumed, reset the timer.
TO SELECT FAN SPEED
• There are 3 fan speeds, as well
as automatic*.
* For automatic fan speed,
the speed of the indoor fan
is automatically adjusted
according to the operation.
• To ventilate air in the room.
• There are 5 selections in addition to automatic
vertical airflow direction.
TO ADjUST AIRFLOw
DIRECTION
• If automatic vertical airflow direction has
been set, the louver swings up and down
automatically.
• Please do not adjust the vertical airflow
direction louver manually.
• Horizontal airflow direction louver could be
adjusted manually.
Select On/OFF timer and Set
the On/OFF time hourly.
Hints
■ Temperature setting of 1°C higher in cool mode or
2°C lower in heat mode than the desired temperature
performs a 10% power saving.
■ To reduce power consumption during cool mode, close
the curtains to prevent the sunlight and heat from
coming in.
To cancel ON or OFF timer, press .
• When you want the air conditioner to turn ON or OFF automatically.
TO SET THE TIMER
FEATURE OPERATION FEATURE OPERATION
TIMER SETTING TIMER SETTING
● To turn off the air conditioner, press .
Confirm
the setting.
