AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
• In heat mode, it takes a while for the unit to warm up. The
power indicator blinks during this operation.
• Recommended temperature: 20°C ~ 24°C
HOw TO OPERATE
Notes:
• Use a screwdriver to short the two Reset Terminals on the
back of remote control to restore the remote control's default
setting.
• Remove the batteries if the unit is not to be used for a long
period.
REMOTE CONTROL TRANSMITTER
AUTO MODE - FOR yOUR CONvENIENCE
HEAT MODE - TO ENjOy wARM AIR
• Make sure it is not
obstructed.
• Certain fluorescent lights
may interfere with signal
transmission. Please
consult your nearest
dealer.
Maximum distances : 8m
INDICATOR INDICATOR
RECEIvER RECEIvER
Close
Insert AAA or
R03 batteries
Pull out
Inserting the batteries
• Unit selects the operation mode according to the room
temperature.
• Once auto mode is selected, the unit will operate at the
standard setting temperature.
• To change the standard setting temperature, press for
“ ” or for “ ”.
Room
temperature
Operation
mode
Standard
setting
temperature (+2°C) (–2°C)
23°C & above Cool 25°C 27°C 23°C
Below 23°C Dry 22°C 24°C 20°C
Below 20°C Heat 21°C 23°C 19°C
• Recommended temperature: 26°C ~ 28°C
COOL MODE - TO ENjOy COOL AIR
• During soft dry operation, the indoor fan operates at low
fan speed to give a very gentle cooling operation.
• Recommended temperature: 1°C ~ 2°C lower than room
temperature.
● For heat, cool and dry modes, the range of
temperature can be selected from 16°C ~ 30°C.
DRy MODE - TO DEHUMIDIFy THE
ENvIRONMENT
Select turn on Adjust
temperature
REMOTE CONTROL PREPARATION REMOTE CONTROL PREPARATION
MODE OPERATION MODE OPERATION
AUTO HEAT
DRY COOL
• The retention period of batteries might be affected
to be shorter because of the using times of the
remote control, even less than one year.
lCD display
