• Use the slots or wire handles
located at both sides to move the
appliance.
[il If the appliance has wire handles,
push the handles back into the
side walls after moving the
appliance.
Connection to the mains supply
Q] This appliance must be
earthed!
Our company shall not be held
responsible for any damage
caused by using the appliance
without an earthed socket.
A Risk of electric shock, short
circuit or fire by unprofessional
installation!
The appliance may be connected
to the mains supply only by an
authorized qualified person and
the appliance is only guaranteed
after correct installation.
A Risk of electric shock, short
circuit or fire by damage of the
mains lead!
The mains lead must not be
clamped, bent or trapped or
come into contact with hot parts
of the appliance.
If the mains lead is damaged, it
must be replaced by a qualified
electrician.
• The mains supply must
correspond to the data specified
on the rating plate of the appliance.
The rating plate can be seen when
the front door is opened.
• The appliance mains cable must
correspond to the specifications
and the power consumption: see
Technical specifications, page 5.
A Risk of electric shock!
Before starting any work on the
electrical installation, please
disconnect the appliance from
the mains supply.
1. If no all-pole separation from the
mains supply is possible, a
separation unit must be connected
with a contact distance of 3 mm
min. (fuses, line safety switches,
contactors) all poles which should
be adjacent to (but not above) the
cooker in accordance with lEE
regulations. Failure to observe this
instruction may result in operational
problems and invalidation of the
appliance warranty.
Additional protection by a residual
current circuit breaker is
recommended.
If a cable without a plug is provided
together with your appliance;
2. for mono-phase connection, take
care to connect as below:
• Brown cable = L (Phase)
• Blue cable = N (Neutral)
11 I EN
