Installing the Multi-Function Center software
1
2
3
4
5
Start Windows 3.1/3.11/95 and close all
applications.
Insert disk #1 into disk drive A (or B).
For Windows 95 users;
Click Start and select Run....
For Windows 3.1 or 3.11 users;
From the Program Manager, click File and
select Run....
At the command line, type “a(or b):\setup" and
click OK.
Follow the instructions on the screen until all
diskettes (disk #2, disk #3) have been
installed.
Remove the disk from the disk drive and click
Finish to reboot your PC.
For Windows 95
For Windows 3.1
Coiranand Line:
aAsstup
Q Run Mmimized
Note:
• If other communication software which uses the serial port has been installed, the communication setting
may be changed and the communication software may not function properly when the Multi-Function Center
software is installed.
•The dialog box images may differ according to applications.
Included applications
The Multi-Function Center contains the following applications and files.
■ Viewer
■ Copier
■ Launch Pad
■ Send From Fax
■ Address Book
■ Finder
■ Message Center
■ ReadMe
Enables you to scan a new image or open an existing image, and then print, fax or edit
that image.
Enables you to copy after scanning a document on the facsimile unit, setting the
reduction, etc., from your PC.
Enables you to launch any Windows application with a single mouse click.
Enables you to fax a document placed on the facsimile.
Enables you to list your personal information database for fax and telephone numbers.
Enables you to access your faxes and scanned documents by the File Name and Key
phrases.
Enables you to manage all incoming and outgoing fax messages and print jobs. The
Message Center application contains five windows that may remain open or be
minimized to one icon within the Message Center main window.
Please read this file before using the Multi-Function Center software.
79
