Panasonic CS-W9 - Инструкция (Страница 6)

6
Remote
Control display
FAN SPEED
AIR SWING
POWERFUL/
QUIET
MODE
A.COMFORT
ECONAVI/
TEMP
TIMER
SET
CANCEL
ON
OFF
1
2
3
SET
CLOCK
RESET
OFF/ON
OFF
TIMER ON
TIMER
FAN
SPEED
AIR
SWING
AUTO
HEAT
COOL
DRY
NANOE-G
3
6
4
2
5
1
8
7
Press the remote control’s button
1 TO TURN ON OR OFF THE UNIT
POWER
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
2 TO SET TEMPERATURE
• For heat, cool and dry modes, the range of temperature
for selection is 16°C ~ 30°C.
• Operating the unit within the recommended temperature
could induce energy saving.
HEAT mode : 20˚C ~ 24˚C.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
3 TO SELECT OPERATION MODE
AUTO mode - For your convenience
• Unit selects the operation mode according to the room
temperature.
• Once auto mode is selected, the unit will operate at the
standard setting temperature.
Room
temperature
Operation mode
Standard setting
temperature
23˚C & above Cool 25˚C
Below 23˚C Dry 22˚C
Below 20˚C Heat 21˚C
• Press for “HI” to +2˚C or for “LO” to -2˚C to the
standard setting temperature.
HEAT mode - To enjoy warm air
• Unit takes a while to warm up. The power indicator blinks
during this operation.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
4 TO SELECT FAN SPEED (3 OPTIONS)
FAN SPEED
• For AUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
REMOTE CONTROL
Maximum
distance: 8m
Human activity
sensor and
indicator
Indicator
(Green)
(Orange)
(Green)
(Green)
(Blue)
(Orange/
Green)
POWER
TIMER
ECONAVI
AUTO COMFORT
NANOE-G
POWERFUL/QUIET
Sunlight sensor and remote control receiver
