Инструкция по эксплуатации Samsung PS63B680T6W
Страница 7
English -
1
COMMON INTERFACE Slot
Insert CI (Common Interface) card into the slot.
(refer to page 27)
When not inserting
CI CARD in some channels,
Scramble Signal is displayed on the screen.
The pairing information containing a telephone number,
CI CARD ID, Host ID, and other information will be
displayed in about 2~3 minutes. If an error message is
displayed, please contact your service provider.
When the channel information configuration has finished,
the message
Updating Completed is displayed,
indicating that the channel list is now updated.
Insert the CI-Card in the direction marked on it.
CAM is not supported in some countries and
regions,check with your authorized dealer.
-
-
-
N
N
2
USB 1(HDD), USB
Connect a USB mass storage device to view photo files
(JPEG) and play audio files (MP3) or movie files. You can
connect to SAMSUNG's network wirelessly.USB 1(HDD)
jack is also used as the HDD jack. HDD (Hard disk drive) is
device which stores digitally encoded data.
3
HDMI IN 4
Connect to the HDMI jack of a device with HDMI output.
4
AV IN (VIDEO, AUDIO L/R)
Video and audio inputs for external devices, such as a
camcorder or VCR.
The product colour and shape may vary depending on the model.
N
TV Side Panel
3
4
1
2
