SETTING UP THE TV A-4
Tidying cables
Install the Power Cord Holder and Power Cord.
It will help prevent the power cable from being
removed by accident. Use Cable Holder to
neatly secure and position cables together.
Position the LAN Cable as shown to reduce the
electromagnetic interference wave.
(Only 42PH47**)
(Only 50PH47**, 50/60PH67**, 50/60PH66**)
Power cord holder
(Depending on model)
CAUTION
y Do not move the TV by holding the cable
holder and power cable holder, as the
cable holders may break, and injuries
and damage to the TV may occur.
NOTE
y When installing the wall mounting
bracket, use the Protection Cover.
y This will protect the opening from
accumulating dust and dirt.
y Remove the stand before installing the
TV on a wall mount by performing the
stand attachment in reverse.
CAUTION
y When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
y Make sure that the screws are inserted
correctly and fastened securely. If they
are not fastened securely enough, the
TV may tilt forward after being installed.
Do not use too much force and over
tighten the screws; otherwise screw may
be damaged and not tighten correctly.
Cable holder
Power cord holder
(Depending on model)
Cable holder
1
2
Protection cover
M5 x 16
1 EA
2
1
2
