ENG
ENGLISH
SETTINGS 19
To synchronize audio and video
SETTINGS AUDIO AV Sync. Adjust
[Depending on model]
Synchronizes video and audio directly when they do
not match.
y If you set AV Sync. Adjust to ON, you can
adjust the sound output (TV speakers or
SPDIF) to the screen image.
To use SIMPLINK
[Depending on model]
SIMPLINK is a feature that enables you to control and
manage various multimedia devices conveniently via
the SIMPLINK menu.
1 Connect the TV’s HDMI IN terminal and the
SIMPLINK device’s HDMI output terminal using an
HDMI cable.
y [Depending on model]
For home theatre units with a SIMPLINK
function, connect HDMI terminals as above,
and use an optical cable to connect Optical
Digital Audio Out from the TV to Optical Digital
Audio In of the SIMPLINK device.
2 Select INPUT(OPTION) SIMPLINK.
SIMPLINK menu window appears.
3 In SIMPLINK Setting window, set SIMPLINK
function to ON.
4 In SIMPLINK menu window, selects the device you
want to control.
y This function is only compatible with devices
with the SIMPLINK logo.
y To use the SIMPLINK function, you need to
use a high-speed HDMI ® cable (with CEC
(Consumer Electronics Control) feature added).
High-speed HDMI ® cables have the No. 13 pin
connected for information exchange between
devices.
y If you switch to another input, the SIMPLINK
device will stop.
y If a third-party device with the HDMI-CEC
function is also used, the SIMPLINK device
may not work normally.
y [Depending on model]
If you select or play media from a the
device with a home theatre function, the HT
Speaker(Speaker) is automatically connected.
Be sure to connect with an optical cable (sold
separately) to use the HT Speaker(Speaker)
function.
SIMPLINK function description
y Direct Play : Plays the multimedia device on
the TV instantly.
y Select multimedia device : Selects the desired
device via the SIMPLINK menu to control it
from the TV screen instantly.
y Disc playback : Manages the multimedia
device with the TV remote control.
y Power off all devices : When you power off
the TV, all connected devices are turned off.
y Sync Power on: When the equipment with
SIMPLINK function connected HDMI terminal
starts to play, the TV will automatically turn on.
y Speaker : [Depending on model]
Select speaker either on the home theatre unit
or the TV.
To set password
SETTINGS LOCK Set Password
Sets or changes the TV password.
The initial password is set to ‘0000’.
When France is selected for Country, password is not
‘0000’ but ‘1234’.
When France is selected for Country, password cannot
be set to ‘0000’.
To return Factory Reset
SETTINGS OPTION Factory Reset
All stored information is deleted and TV settings are
reset.
The TV turns itself off and back on, and all settings are
reset.
y When Lock System is in place, a pop-up
window appears and asks for password
y Do not turn off the power during initialization.
To remove the USB device
Q.MENU USB Device
Select a USB storage device that you want to remove.
When you see a message that the USB device has
been removed, separate the device from the TV.
y Once a USB device has been selected for
removal, it can no longer be read. Remove the
USB storage device and then re-connect it.
