ENG
ENGLISH
ASSEMBLING AND PREPARING 15
CAUTION
y Disconnect the power first, and then move or
install the TV. Otherwise electric shock may
occur.
y If you install the TV on a ceiling or slanted wall, it
may fall and result in severe injury.
Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
y Do not over tighten the screws as this may cause
damage to the TV and void your warranty.
y Use the screws and wall mounts that meet the
VESA standard. Any damages or injuries by
misuse or using an improper accessory are not
covered by the warranty.
y Screw length from outer surface of back cover
should be under 8mm.
Wall mount Pad
Back Cover
Standard screw
: M4 x L10
Wall mount Pad
Back Cover
Max.8mm
NOTE
y Use the screws that are listed on the VESA
standard screw specifications.
y The wall mount kit includes an installation
manual and necessary parts.
y The wall mount bracket is not provided. You can
obtain additional accessories from your local
dealer.
y The length of screws may differ depending on the
wall mount. Make sure to use the proper length.
y For more information, refer to the manual
supplied with the wall mount.
Mounting on a wall
Attach an optional wall mount bracket at the rear of the
TV carefully and install the wall mount bracket on a
solid wall perpendicular to the floor. When you attach
the TV to other building materials, please contact
qualified personnel.
LG recommends that wall mounting be performed by a
qualified professional installer.
We recommend the use of LG’s wall mount bracket.
When you do not use LG’s wall mount bracket,
please use a wall mount bracket where the device is
adequately secured to the wall with enough space to
allow connectivity to external devices.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount bracket that
meet the VESA standard. Standard dimensions for the
wall mount kits are described in the following table.
Separate purchase(Wall Mounting Bracket)
Model 22/24LB45** 28LB45**
VESA (A x B) 75 x 75 100 x 100
Standard screw M4 x L10
Number of screws 4
Wall mount bracket LSW140
A
B
