Quick Reference Guide
21
yellow
green
yellow
yellow
A possible processor failure has
occurred. • Reinstall the processor and restart the computer.
green
green
yellow
yellow
Memory modules are detected, but a
memory failure has occurred. • If you have one memory module installed, reinstall it and
restart the computer.
• If you have two memory modules installed, remove the
modules, reinstall one module, and then restart the
computer. If the computer starts normally, reinstall the
second module.
• If available, install properly working memory of the same
type into your computer.
• If the problem persists, contact Dell.
yellow
yellow
green
yellow
A possible PCI expansion card failure
has occurred. • Determine if a conflict exists by removing a card (not the
video card) and then restarting the computer.
• If the problem persists, reinstall the card that you
removed, remove a different card, and then restart the
computer.
• Repeat this process for each card. If the computer starts
normally, troubleshoot the last card removed from the
computer for resource conflicts (see ""Resolving Software
and Hardware Incompatibilities" on page 24").
• Move each card one at a time to a different PCI slot and
restart the computer after each move.
• If the problem persists, contact Dell.
yellow
green
green
yellow
A possible IDE drive failure has
occurred. • Reseat all IDE drive power and data cables and restart the
computer.
green
green
green
yellow
A possible USB failure has occurred. • Reinstall all USB devices, check cable connections, and
then restart the computer.
Light
Pattern Problem Description Suggested Resolution
