6
3. POWER button: pressing this button you can switch on or off the unit.
4. SLEEP button: after pressing this button the fan sets to low speed.
(1) Press SLEEP button, set the sleep mode. Press the button again to cancel
the sleep mode.
(2) In the cooling mode one hour after the sleep mode is set the temperature
automatically increases by 1°C. In two hours the temperature will increase by
2°C and the established mode is maintained for the rest of the time. In the
heating mode when SLEEP function is activated the temperature is, on the
contrary, decreased by 2°C in 2 hours.
(3) When power supply is turned off, the sleep mode is automatically switched
off.
(4) When the unit is turned off, settings of the sleep mode are automatically
turned off.
5. Timer button: ON TIMER: The ON timer is used to automatically switch on the
unit upon expiration of the set time.
(1) Press TIMER button when the unit is OFF to set the desired time.
(2) After the set time expires, the unit will be automatically switched on.
(3) Press ON/OFF button before the set time expires. Time setting will be
canceled and the unit will be switched on.
OFF TIMER: The OFF timer is used to automatically switch off the unit upon
expiration of the set time.
(1) Press TIMER button when the unit is ON to set the desired time.
(2) After the set time expires, the unit will be automatically switched off.
(3) Press ON/OFF button before the set time expires. Time setting will be
canceled and the unit will be switched off.
6. Automatic fan speed button (automatic ventilation mode).
7. High speed button. High fan speed.
8. Medium speed button. Medium fan speed.
9. Low speed button. Low fan speed.
(2) In the cooling mode one hour after the sleep mode is set the
temperature automatically increases by 1°C. In two hours the temperature
will increase by 2°C and the established mode is maintained for the rest of
the time. In the heating mode when SLEEP function is activated the
temperature is, on the contrary, decreased by 2°C in 2 hours.
(3) When power supply is turned off, the sleep mode is automatically
switched off.
(4) When the unit is turned off, settings of the sleep mode are automatically
turned off.
The portable air conditioner is equipped with a protective circuit featuring a
3 minute compressor activation delay. It means that it takes 3.5 minutes for
the compressor to activate after the unit is switched on or dehumidification
mode is switched to any other mode.
9. Signaling.
E4 signal is shown on the display at the maximum water level. To resume
operation, remove the rubber plug of the drainage hose at the device's base
to drain water at first. After water is drained, start the unit. It will go to the
normal operating mode.
Indicators for operating mode:
- cooling mode indicator
- heating mode indicator
- dry mode indicator
- sleep mode indicator
- operation indicator
Remote control (only for AC TIM 09HE P4)
5
7
6
3
4
2
1
1. FUNC mode selection button (SET):
You can select three functions with this button: cooling, heating and
dehumidification.
2. Room temperature setting button (TEMP): The set temperature is raised by
1°C after a single press on up button and is lowered by 1°C after a single press
on down button.
www.timberk.com electric floor standing air onditioner ortable type (single case)
9
8
Fig. 9
