PLANET VoIP Телефоны серии VIP-103PT/153PT/153T/153M. Инструкция по эксплуатации
36
ШАГ 3:
Repeat the same configuration
Шагs on VIP-153T, and check the machine registration status, make
sure the registrations are completed.
Test the scenario:
To verify the VoIP communication, you may make calls from SIP client (VIP-153PT) 1001 to the number 1002
(VIP-153T) or reversely make calls from SIP client (VIP-153T) 1002 to the number 1001 (VIP-153PT)
Voice communication via IP PBX system – IPX-2000 (Auto-config)
In the following sample, we’ll introduce how to integrate the SIP Phone with our IP PBX system IPX-2000 via
Auto-config feature.
Registration /
Authentication
Registration /
Authentication
VIP-153T
IP
Address:
192.168.0.2
Line Number: 2002
VIP-153PT
IP
Address:
192.168.0.1
Line Number: 1001
IPX-2000 LAN IP Address: 192.168.0.50
Machine configurations on the IPX-2000:
ШАГ 1:
Log in IPX-2000 and browse to the DHCP menu and create new options list for the auto configuration.
Code: please insert 151 as the DHCP server option.
Value: http://LAN IP for IPX-2000/tftpboot
If you’d like to enable auto-config for IP extension features in IPX-2000, please be sure to setup the DHCP option code and the value
information.
In most case, insert the optional code 151 and the value=http://192.168.0.50/tftpboot/
• 192.168.0.50 is the IP address of IPX-2000
L
Внимание!
