PLANET VoIP Телефоны серии VIP-103PT/153PT/153T/153M. Инструкция по эксплуатации
35
ШАГ 2:
After these configurations, be sure to click the “DONE” button to apply settings and browse to “System
Configuration” menu to reboot the machine to make the settings effective. After rebooting, the unit will
communicate with the remote calling party, the LCD screen will show below:
Registering (100)
Nov 16 12:10
ШАГ 3:
At this moment, you may pick up the handset and dial “200” to connect the remote VIP-153T to start the voice
communications.
Voice communication via SIP proxy server – SIP-50
Registration /
Authentication
Registration /
Authentication
SIP-50 IP Address: 192.168.0.50
VIP-153PT WAN IP Address: 192.168.0.1
Line Number: 1001
VIP-153T WAN IP Address: 192.168.0.2
Line Number: 2002
Machine configurations on the VIP-153PT/VIP-153T:
ШАГ 1:
Log in SIP-50 and create two testing accounts/password: 1001/123 (for VIP-153PT), and
1002/123(for VIP-153T) for the voice calls.
ШАГ 2:
Please log in VIP-153PT via web browser, browse to the SIP setting menu and select the Domain
Service config menu. In the setting page, please insert the account/password information obtained
from your service provider (in this sample, we’re using PLANET SIP-50 as the SIP Proxy server for
SIP account, call authentications), and then the sample configuration screen is shown below:
